a2

G3 Four-Piston

professional hydraulic disc brake
especially for off road / moped type ELECTRIC BIKE

SYSTEM

Open system, 4-piston

Recommend for e-bike with mid-motor

Easy installation, adjustment and maintenance

be good braking effect for bikes with large torque and strong power

CALIPER

4-Piston, Forged Aluminum body

Free angle of hose connector for varied frames

Easy installation & maintenance from top

Finish : Black

WEIGHT

Front wheel - 395 grams / Rear wheel - 301 grams

( Exclude rotor, adapter & mounting bolts )

LEVER

Forged aluminum lever / Cast aluminum bracket

I-Spec Il & Matchmaker compatible

Reach adjustment

Two pieces hinged bracket

4 finger blade

Finish : Black

ROTOR

Wave type (G180), 2.3mm thickness

High heat dispersion & heat tolerance

Diameter : Ø180mm

Also available : Ø203mm

PADS

Durable and high performance sintered pad

Replacement : Ceramic/Resin
